60 Degree Bevel Edge Forming 1/2" Shank Router Bit

While bevel bits are mostly used for edging, these 60 degree chamfer and bevel edge forming router bits can also be used to create miter joints of various angles. Some of the available angle degrees are 11.25°, 15°, 22.5°, 30° & 45°. Cutting these angles into 2 adjoining pieces of wood will create miter joints of 22.5°, 30°, 45°, 60° & 90° degrees respectively.

This bit will cut 60° bevels and chamfers at 1" deep and 9/16" high. This bit will also create a 120° angle miter joint. Two flute carbide cutters and 1/2" Shank.

Bit Specs
Material:Carbide Tipped
Degrees:60°
Number of Flutes:2
Number of Bits:1
Overall Length:2-3/4"
Largest Diameter:2-1/2"
Shank Size:1/2"
Cutting Length:9/16"
Cutting Depth:1"
